Powering the AC Power Supply Module
To power the CPSMC1800-200 and the CPSMC1850-150 PointSystem™ chassis
through the AC power supply module:
1. Set the On/Off switch to "0".
2. Connect female end of the power cord to the AC power connector on the power
3. Plug the male end of the power cord into the correct voltage AC rack or wall
4. Set the On/Off switch to "I".
5. Verify that the chassis is powered by observing the illuminated power LED and
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
supply module.
socket.
fan operation.
AC Power Connector
Fan
Power LED
CPSMC18xx-xxx PointSystem™ Chassis
On/Off Switch
I
0
I
0
AC Power Cord
15
