2.2.3

Replacing the Management Modules

CAUTION:
precautions when replacing the media converter slide-in-module(s). Failure to
observe this caution could result in damage to, and subsequent failure of, the
management module(s).
NOTE: The management modules can be replaced while the chassis remains
powered. However, you must configure a new IP address for the replacement
management module. For more information, see the FocalPoint™ 2.0 user's guide
on the enclosed application CD or on-line at www.transition.com.
To replace a management module in the CPSMC18xx-xxx chassis:
1. Remove the management module to be replaced by loosening the panel
2. Align the replacement Management module with the installation slot so that the
3. Carefully slide the replacement management module into the installation slot,
4. Push in and rotate the attached panel fastener screw clockwise to secure the
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Wear a grounding device and observe electrostatic discharge
fastener screw that secures the module to the chassis front. Slide the module
from the chassis.
panel fastener screw is at the top.
Conversion
Center PS
Power
1
In Use
Power
2
In Use
ESD
Gnd.
Term.
RESET
Pwr
INIT
CPSMC1800 CPSMC1800
TERM
Panel Fastener Screw
while aligning the module's circuit board with the installation guides.
NOTE: Ensure that the management module is firmly seated inside the chassis.
module to the chassis.
CPSMC18xx-xxx PointSystem ™ Chassis
13
