Transition Networks PointSystem CPSMC1810-200 User Manual page 26

To install the CPSMC18xx-xxx chassis into a standard 19-inch rack:
1. Determine the preferred alignment of the chassis in the rack.
2. Locate six (6) installation bracket mounting screws (provided) for each chassis
3. Align the universal mounting bracket in the selected position against the side of
4. Using a Phillips screwdriver, install the three (3) screws through the mounting
5. Repeat steps 3 and 4 for the second mounting bracket.
6. Locate four (4) screws (not provided) and optional clip-nuts (not provided) for
7. Carefully align the chassis at a secure and level position between the 19-inch
8. Install two (2) screws through the right bracket into the right mounting rail and
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
NOTE: Installation bracket mounting screws are provided. Rack mount screws
and clip nuts are NOT provided.
to be installed.
WARNING: Mount the chassis evenly and securely onto the rack. Failure to
observe this warning could allow the chassis to fall, resulting in equipment
damage and/or possible injury to personnel.
the chassis so that the chassis installation holes are visible through the universal
bracket installation holes.
bracket into the installation holes on side of the chassis.
Conversion
Center PS
Power
1
In Use
Power
2
In Use
ESD
Gnd.
Term.
CPSMC1800 CPSMC1800
each chassis to be installed.
CPSMC1800
site rack mounting rails.
two (2) screws through the left bracket into the left mounting rail, using the clip
CPSMC1800
nuts to secure, if necessary.
Media
Conversion
Center
Power
1
In Use
Power
2
In Use
ESD
Gnd.
Term.
CPSMC1800 CPSMC1800
CPSMC18xx-xxx PointSystem ™ Chassis
