2.2.2

Installing the Management Modules

CAUTION:
precautions when installing the management module into the CPSMC18xx-xxx
chassis. Failure to observe this caution could result in damage to, and subsequent
failure of, the management module.
NOTE: Transition Networks recommends installing the management module into
the left-most installation slot to keep the management module cables separate from
the media converter cables.
To install a management module into the CPSMC18xx-xxx chassis:
1a. CPSMM-200 Dual-Slot Master Management Module:
1b. CPSMM-120 Single-Slot Master Management Module OR
2. Align the management module with the chassis installation slot so that the
3. Carefully slide the management module into the installation slot, while aligning
4. Push in and rotate the attached panel fastener screw clockwise to secure the
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Wear a grounding device and observe electrostatic discharge
chassis face plates are covering the installation slots, remove the face plates
from the two (2) installation slots at the far-left position of the chassis.
Conversion
Center PS
Power
1
In Use
Power
2
In Use
TX PWR
ESD
Gnd.
Term.
RX LNK
RESET
CPSMC1800 CPSMC1800
Panel Fastener Screw
MCCM10
MGMT MASTER
CPSMM-210 Single-Slot Expansion Management Module:
If chassis face plates are covering the installation slots, remove the face plate
from the one (1) installation slot at the far-left position of the chassis.
Conversion
Center PS
Power
1
In Use
Power
2
In Use
ESD
Gnd.
Term.
RESET
Pwr
INIT
CPSMC1800 CPSMC1800
TERM
Panel Fastener Screw
panel fastener screw is at the top of the module.
the module's circuit board with the installation guides.
NOTE: Ensure that management module is firmly seated inside the chassis.
management module to the chassis.
CPSMC18xx-xxx PointSystem ™ Chassis
