Chapter 5: ChipScope Engine Tcl Interface
::chipscope::csevio_read_values
Reads values from the specified signal/bus of the target VIO core.
Syntax
Arguments
Table 5-70: Arguments for Subcommand ::chipscope::csevio_read_values
Returns
An exception is thrown if the command fails.
Example
Assumptions for this example:
•
•
•
1.
204
::chipscope::csevio_read_values handle [list deviceIndex userRegNumber
coreIndex] inputTclArray
Argument Type
handle
[list
deviceIndex
userRegNumber
coreIndex]
inputTclArray
Required
coreRef has already been set to the VIO core.
A signal called "status" is defined as a bit in the SYNC_INPUT port.
A bus called "data_bus" is defined as an 8-bit bus in the ASYNC_INPUT port.
Get the values of " status " and " data_bus " and print them to stdout
%csevio_read_values $handle $coreRef inputTclArray
www.xilinx.com
Description
Handle to the session that is returned by
::chipscope::csejtag_session create
A list containing three elements:
• Device index (0 to n-1) in the n-length JTAG chain
• BSCAN block USER register number (starting with 1)
• Index for core unit. First core unit connected to ICON has
index 0.
Name of a Tcl array. The index into the array is the name of
an input signal or bus defined by
csevio_define_signal or csevio_define_bus,
respectively. Special postfixes can be used to specify various
states of the input signal or buses:
• ".value" specifies the signal/bus value (same as no
postfix)
• ".activity_up" specifies asynchronous low-to-high
activity
• ".activity_down" specifies asynchronous high-to-
low activity
• ".sync_activity_up" specifies the synchronous
low-to-high activity (only valid for SYNC_INPUT
signals/buses)
• ".sync_activity_down" specifies the synchronous
high-to-low activity (only valid for SYNC_INPUT
signals/buses)
