CseVIO Tcl Commands
The following CseFpga Commands are described in detail in this section:
•
•
•
•
•
•
•
•
•
::chipscope::csevio_get_core_info
Reads the status word from the target VIO core.
Syntax
Arguments
Table 5-62: Arguments for Subcommand ::chipscope::csevio_get_core_info
ChipScope Pro Software and Cores User Guide
UG029 (v14.3) October 16, 2012
::chipscope::csevio_get_core_info
::chipscope::csevio_is_vio_core
::chipscope::csevio_init_core
::chipscope::csevio_terminate_core
::chipscope::csevio_define_signal
::chipscope::csevio_define_bus
::chipscope::csevio_undefine_name
::chipscope::csevio_write_values
::chipscope::csevio_read_values
::chipscope::csevio_get_core_info handle [list deviceIndex
userRegNumber coreIndex] coreInfoTclArray
Argument Type
handle
[list
deviceIndex
userRegNumber
Required
coreIndex]
coreInfoTclArray
www.xilinx.com
Description
Handle to the session that is returned by
::chipscope::csejtag_session create
A list containing three elements:
• Device index (0 to n-1) in the n-length JTAG chain
• BSCAN block USER register number (starting with 1)
• Index for core unit. First core unit connected to ICON
has index 0.
Tcl array name. After the command is executed
successfully, the array contains information described in
the Returns section below.
CseVIO Tcl Commands
