Table 1-11: IBERT v2.00a core for 7 Series FPGA GTZ Transceivers
ChipScope Pro Software and Cores User Guide
UG029 (v14.3) October 16, 2012
Feature
Multiple GTZ Transceivers
Pattern Generator
Pattern Checker
Fabric Width
Polarity
Reset
Link and Lock Status
DRP Read
DRP Write
Ports Read
Ports Write
Status
www.xilinx.com
ChipScope Pro Cores Description
Description
Up to eight transceivers can be selected per design.
One pattern generator per selected GTZ transceiver is used.
PRBS 7-bit, PRBS 15-bit PRBS 23-bit, PRBS 31-bit, Clk 2x, and
Clk 10x patterns are available. The desired pattern from that
set can be selected individually for each GTZ transceiver at
runtime.
One pattern checker per selected GTZ transceiver is used.
The same pattern set is available as the pattern generator. The
pattern can be chosen for each GTZ transceiver at runtime.
The FPGA fabric interface to the GTZ transceiver can only be
160 bits wide.
The polarity of the TX side of each GTZ transceiver can be
changed at runtime.
Each GTZ transceiver can be reset independently. A reset is
also available to reset the entire MGT, including PLLs and
CPLLs.
Link, and CPLL/QPLL lock status are gathered for each GTZ
transceiver in the core.
The contents of the DRP space for each GTZ transceiver can
be read independently of all others.
The contents of the DRP for each GTZ transceiver can be
changed at runtime, with single-bit granularity.
The contents of the registers that monitor the GTZ transceiver
ports can be read independently of others.
The contents of the registers that control the GTZ
transceiver's ports can be changed at runtime.
The dynamic status information for the entire core can be
read out of the core at runtime.
