Chapter 4: Using the ChipScope Pro Analyzer
Reset All
To reset all the channels in the IBERT core, select IBERT_V7GTZ > Reset All or click the
Reset All button in the toolbar.
JTAG Scan Rate and Scan Now
Use the JTAG Scan Rate toolbar and IBERT_V7GTZ > JTAG Scan Rate menu options to
select how frequently the ChipScope Pro Analyzer tool queries the IBERT core for status
information. The default is 1s between queries, but you can select 250 ms, 500 ms, 1s, 2s, 5s,
or Manual Scan. When you select Manual Scan, use IBERT_V7GTZ > Scan Now or the
Scan Now (or S!) toolbar button to query the IBERT core.
Standalone IBERT Sweep Test Plot Viewer
The plot viewer in the Sweep Test panel of the IBERT Console can only be used to sweep
test results while you are connected to the live device under test. If you want to view the
sweep test results offline, you can use the standalone IBERT sweep test plot viewer:
•
•
•
•
You can use the standalone IBERT sweep test plot viewer to view CSV sweep test result
files that were created by running IBERT sweep tests on the following transceivers:
•
•
•
•
•
You can also use the IBERT sweep test plot viewer to view multiple sweep test result CSV
files at the same time. This is useful for comparing the results of different sweep test runs.
Help Pages
The ChipScope Pro Analyzer tool help pages contain information for only the currently
opened versions of the software and each of the core units. Selecting Help > About:
ChipScope Software displays the version of the software. Selecting Help > About: Cores
displays detailed core parameters for every detected core. Individual core parameters can
be displayed by right-clicking on the unit in the project tree and selecting Show Core Info.
ChipScope Pro ILA Waveform Toolbar Features
In addition to the menu options, other ChipScope Pro Analyzer ILA waveform commands
are available on a toolbar residing directly below the ChipScope Pro Analyzer menu. The
second set of toolbar buttons is available only when the Trigger Setup window is open. The
third and fourth sets of toolbar buttons are only available when the Waveform window is
active.
The toolbar buttons correspond to the following equivalent menu options:
128
On Windows (32-bit) platforms: <install dir>\bin\nt\ibertplotter.exe
On Windows (64-bit) platforms: <install dir>\bin\nt64\ibertplotter.exe
On Linux (32-bit) platforms: <install dir>/bin/lin/ibertplotter
On Linux (64-bit) platforms: <install dir>/bin/lin64/ibertplotter
Spartan-6 FPGA GTP transceivers
Virtex-5 FPGA GTX transceivers
Virtex-6 FPGA GTX transceivers
Virtex-6 FPGA GTH transceivers
7 Series FPGA GTX transceivers
