Chapter 5: ChipScope Engine Tcl Interface
CseCore Tcl Commands
The following CseFpga Commands are described in detail in this section:
•
•
•
::chipscope::csecore_get_core_count
Gets the number of cores attached to an ICON core that is in the target FPGA device and
attached to a particular USER scan chain register.
Syntax
Arguments
Table 5-59: Arguments for Subcommand ::chipscope::csecore_get_core_count
Returns
The number of cores.
An exception is thrown if the command fails.
Example
Get the number of cores attached to the ICON core in the USER3 register of the third device
in the JTAG chain.
Back to list of all CseCore Tcl Commands
192
::chipscope::csecore_get_core_count
::chipscope::csecore_get_core_status
::chipscope::csecore_is_cores_supported
::chipscope::csecore_get_core_count handle deviceIndex userRegNumber
Argument Type
handle
Required
deviceIndex
userRegNumber
%set coreCount [csecore_get_core_count $handle 2 3]
www.xilinx.com
Description
Handle to the session that is returned by
::chipscope::csejtag_session create
Device index (0 to n-1) in the n-length JTAG chain.
BSCAN block USER register number (starting with 1)
ChipScope Pro Software and Cores User Guide
UG029 (v14.3) October 16, 2012
