Chapter 5: ChipScope Engine Tcl Interface
::chipscope::csejtag_session create
This is typically the first subcommand call made to the ChipScope Engine. The session
handle that is returned by this command allows you to open and control JTAG targets. This
command also initializes the session with data obtained from various data files located in
the default directory called <LIBCSEJTAG_DLL_PATH>/../../data/cse , where
<LIBCSEJTAG_DLL_PATH>
Syntax
Arguments
Table 5-10: Arguments for Subcommand ::chipscope::csejtag_session create
Returns
A session handle. An exception is thrown if the command fails.
Example
1.
2.
Back to list of all CseJtag Tcl Commands
138
::chipscope::csejtag_session create messageRouterFn [opt_args...]
Note: [opt_args...]
Argument Type
Required
messageRouterFn
Optional
-server <host>
Optional
-port <portnum>
Create a new session with no optional arguments.
%set handle [::chipscope::csejtag_session create messageRouterFn]
Create a new session using the client/server libraries to a server called lab_machine
at port "50001".
%set handle [::chipscope::csejtag_session create messageRouterFn
-server "lab_machine" -port "50001"]
www.xilinx.com
denotes the absolute location of the libCseJtag.dll file.
is an optional list of arguments in string or list of string form.
Message router function name. Use a value of 0 to route
all messages to stdout. Sample function declaration:
proc messageRouterFn {handle msgFlags
msg} { ... }
msgFlags return one of the following:
$CSE_MSG_ERROR
$CSE_MSG_WARNING
$CSE_MSG_STATUS
$CSE_MSG_INFO
$CSE_MSG_NOISE
$CSE_MSG_DEBUG
Creates a session associated with the ChipScope server
host name denoted by <cs_server_host_name>.
Creates a session associated with the ChipScope server
port number denoted by <cs_server_port_number>.
ChipScope Pro Software and Cores User Guide
Description
