Chapter 4: Using the ChipScope Pro Analyzer
X/O Cursor Values
You can choose whether or not to include the X/O cursor values in the waveform printout.
If you choose to display the X/O cursor values in the waveform printout, they appear on
each page or only on the first page, depending on the Print Signal Names setting.
Footer
You can enable or disable the inclusion of a footer at the bottom of each page by selecting
the Show Footer checkbox. The footer contains useful information including the
ChipScope Pro Analyzer project name, waveform settings, print settings, and page
numbers.
Navigation Buttons
The buttons at the bottom of the Print Wizard (1 of 3) window are defined as follows:
•
•
•
Clicking on the Next button takes you to the Print Wizard (2 of 3) window.
Print Wizard (2 of 3) Window
The second Print Wizard window shows a preview of the waveform printout.
Page Preview Buttons
The buttons at the top of the page control which page of the waveform printout is being
previewed as follow:
•
•
•
Navigation Buttons
The buttons at the bottom of the Print Wizard (2 of 3) window are defined as follows:
•
•
•
•
Bus Expansion and Contraction
You can manipulate the waveform by expanding and contracting the buses in the print
preview window. For example, if you expand a bus in such that it pushes other
signals/buses to another page, the total print preview page count at the top changes
accordingly.
Print Wizard (3 of 3) Window
In the Print Wizard (2 of 3) window, clicking on the Send to PDF button goes to the Print
Wizard (3 of 3) PDF confirmation window. Clicking on the Yes button causes the waveform
printout to be written to the specified PDF file while clicking on the No button returns you
58
Page Setup: Opens the page setup window
Next: Opens the Print Wizard (2 of 3) window
Cancel: Closes the Print Wizard window without printing
The << and >> buttons go to the first and last preview pages, respectively
The < and > buttons go to the previous and next preview pages, respectively
The text box in the middle can be used to go to a specific preview page
Back: Returns to the Print Wizard (1 of 3) window
Send to PDF: Opens the Print Wizard (3 of 3) window for writing directly to a PDF File
Send to Printer: Opens the Print Wizard (3 of 3) window for sending to a printer
Close: Closes the Print Wizard window without printing
