Paper parameters (Paper)

Selects the paper parameters Formlen (form length), FormAdj (first printing
position) and Head (printhead gap, only if AGA=Off) separately for each paper
source in the current menu.
Non-installed and with the parameter PapOpt activated options cannot be selected.
Paper AutoTear
Back Next
1 2 3
Trac1
Select the desired paperway, in our example Trac1 (2). Press Next (4) key, to proceed to the installed
optional paperways.

Form length (Forml)

You can define the form length in one of two ways: via the number of lines or via
standard formats (e.g. Letter 11").
Forml FormAdj
Back Next
1 2 3
Lines Standard
Back Next
1 2 3
6 LPI = 66
Set < > Exit
1 2 3
Sets the form length via line formats. Please note that the adjustment in Lines depends on the
selected LPI. For example 8 LPI at a selected line number of 88 lines results in a formlength of 11
inches (88 lines/[8lines/inch]) = 11 inches). The selectable range is between 1 and 22 inches, i.e. for 2
LPI from 2 to 44 lines and for 12 LPI from 12 to 264 lines.
If the form length is set it will not be changed by changing the LPI later on.
Confirm the setting by pressing the Set key (1).
Online
Press Paper (2) key.
4
Setup
You can now choose between the following paper options:
► Tractor 1
► Tractor 2 (front, option)
Online
Press Forml (2) key.
4
Setup
Online
If you wish to define the form length via a line format, press
4
Line (2) key.
Setup
*
Online
Use the < (2) or > (3) key to select the desired setting.
4
Setup
Setting Options: 6 to 144
Default Setting: 66
The menu
