The control panel
Key functions when turning on the printer
If you keep one of the following keys pressed during power-on until the printer has completed
initialization, the corresponding function is activated:
▸
If you keep the Online key depressed while turning on the printer, you enter the printer's
advanced menu mode. The advanced menu mode is described in the section
this manual.
▸
If you keep the Setup key depressed while turning on the printer, you regain access to the printer
menu if you had locked it before with the help of the MenLock function. The MenLock function is
described in the section
▸
If the four function and select keys (keys 1 to 4) are depressed simultaneously while turning on
the power, all printer settings are reset to the default values, except the Forml (Form length)
setting in advanced menu mode.
This causes all the user's previous settings to be lost.
USB host interface
The printer is equipped with a USB host interface. A standard USB memory
device can be plugged into this interface and can then be used for firmware
download and config file up- and download. The USB device must be formatted
with FAT16 or FAT32 file system, other formats like NTFS are not supported. It is
strongly recommended to use an empty and newly formatted device; otherwise
the data transfer may not work. The firmware or config files for download must
always be located in the root directory! The format of the config files is the same
that is used when you up-/download the printer configuration via the webpanel or
via the config tool.
Firmware Download
This function will be activated by pressing key 1 during power on. The display
now shows USBH firm. down. and Insert USB stick. After a USB stick was
connected, the printer will search the root directory for a file with the extension
*.mot. If more than one file with this extension is found, the first one will be used.
If no file was found, the display will show no file found. After the download was
completed, the printer will reboot.
Configuration File Upload
This function will be activated by pressing key 2 during power on. The display will
now show upload cfg file. and Insert USB stick. After a USB stick was
connected, the printer will write the config file (extension *.cfg) to the USB stick.
The file name is the same as the firmware ID number. During the write time, the
display will show please wait. If the same file already exists, the display will show
cfg file exists and please delete it. Then the user should delete the file and try it
again. After the upload was completed, the printer will reboot.
24
Menu lock
(MenLock).
User Guide
Advanced menu
of
