The LC display

The LC display tells you all the important printer settings and informs you which functions are currently
assigned to which keys.
The upper line informs you that the printer is either in online or offline mode (in the example below the
printer is in the Ready mode), and the selected paperpath (below: Trac1 = Tractor 1 = tractor mode,
Status lists which Macro is selected and its emulation, with key 4 is currently activating the Loading of
the Paper).
Example:
Printer status Paper path
Key functions
Ready Trac1
Status messages
Online
MX YYY Load
1 2 3 4
Setup
