Ethernet interface (ETH-INT)

In this parameter group you can choose settings for the internal Ethernet interface.
ETH-INT
Back Next
1 2 3
If an optional Ethernet print server (modular or pocket) is installed, ETH-EXT
can be set via key 3 in the same manner as described below.

Setting Gateway address (Gateway)

Input of the Gateway address into the printer. This is usually the Routers IP Address.
Gateway IPv4Addr
Back Next
1 2 3
OCTET 1 OCTET 2
Back Next
1 2 3
OCTET 1= 0
Set < > Exit
1 2 3
Confirm the setting by pressing the Set key (1).
Set the remaining three digit groups in the same way.
Press the Next key (4) to access the next group of parameters.
Online
Press ETH-INT (2) key.
4
Setup
Online
Press Gateway (2) key.
4
Setup
This menu level offers the possibility to set the IP address,
which is divided into four digit groups (octet 1 to 4). You can
Online
activate octet 3 and 4 by pressing the Next (2) key.
4
Setup
Press OCTET 1 (1) key.
Use the < (2) or > (3) key to select the desired digit.
*
Online
Setting Options: 0 to 255
Default Setting: 0
4
Setup
The menu
