Analog Devices ADAU1961 Manual page 45

Byte Bits
4 [6:3]
4 [2:1]
4 0
5 1
5 0
Downloaded from Elcodis.com electronic components distributor
Bit Name Description
R[3:0] PLL integer setting.
Setting
0010
0011
0100
0101
0110
0111
1000
X[1:0] PLL input clock divider.
Setting
00
01
10
11
Type Type of PLL. When set to integer mode, the values of M and N are ignored.
0 = integer (default).
1 = fractional.
Lock PLL lock. This read-only bit is flagged when the PLL has finished locking.
0 = PLL unlocked (default).
1 = PLL locked.
PLLEN PLL enable.
0 = PLL disabled (default).
1 = PLL enabled.
Value of R
2 (default)
3
4
5
6
7
8
Value of X
1 (default)
2
3
4
Rev. 0 | Page 45 of 76
ADAU1961
