Using The Cursors

Zoom
window
on active
cursor
Figure 2–5: Cursors A and B. Cursor A is the Active Cursor.
Use Cursor A and Cursor B to make additional measurements on the
waveform. Distance measurements from the front panel to the cursor
locations are displayed at the top of each cursor.
The inactive cursor is activated (made moveable) by pushing the
arrow keys when the
The active cursor is longer than the inactive cursor, and has the zoom
window centered on it. The zoom window defines the area of the
waveform that magnifies (expands to fill the screen) when the
zooming the waveform.
Information boxes at top and bottom screen list measurement data at
the location of the cursors. The boxes at top screen and the Event
TFS3031 TekRanger/TekRanger 2 User Manual
softkey. Move the active cursor by pushing the
softkey is pushed. See page 2–19 for information about
button is in Cursor mode.
Testing A Fiber
2–15
