Testing A Fiber
2–10
placement. The zoom window is always centered on the
currently active (moveable) cursor.
See page 2–19 for information about zooming the
waveform.
The
cursor is active (moveable). Move the active cursor by
pushing the arrow keys when the
Cursor mode.
In Figure 2–2, cursor A is the currently active cursor.
button options are: Cursor, Zoom, and Trace.
See page 2–17 for information about
options.
TFS3031 TekRanger/TekRanger 2 User Manual
softkey toggles between which
button is in
button
