Setups
Reflectance
Reflectance is the ratio of reflected optical power to incident optical
power for reflective events.
In the event table display, Reflectance specifies the position of the
Reflectance data column relative to the other columns in the table, or
turns the Reflectance column off.
Selections are columns 1 through 10; Off. Factory default is
column 3.
Slope
Slope is attenuation of the fiber between an event and the preceding
event.
In the event table display, Slope specifies the position of the Slope
data column relative to the other columns in the table, or turns the
Slope column off.
Selections are columns 1 through 10; Off. Factory default is
column 4.
Dead Zone
Dead zone is the distance from the beginning of an event to the point
at which backscatter is detected, and subsequent events can be
accurately detected and measured.
In the event table display, Dead Zone specifies the position of the
Dead Zone data column relative to the other columns in the table, or
turns the Dead Zone column off.
Selections are columns 1 through 10; Off. Factory default is off.
