Setup Summary Tables; Table 1-1: Test Setup Menu - Tektronix ATECTekRanger User Manual

Setup Summary Tables

Instructions on how to change setups begin on page 1–17.
Setup descriptions begin on page 1–21.
Table 1–1: Test Setup Menu
Setup
Fiber Scan
(Test Mode)
Test Range
Pulsewidth
Averages
Splice Threshold
Reflectance
Threshold
Scan For
End of Fiber
Threshold
Refractive Index
Scattering Coeffi-
cient
TFS3031 TekRanger/TekRanger 2 User Manual
Parameters
IntelliTrace
Manual
End of fiber
Wavelength dependent
Wavelength dependent
256 to 4,194,304
SM:0.02 to 5.00 dB
MM: 0.02 to 5.00 dB
0.01 dB steps
–60.0 dB to –20.0 dB in
5.0 dB steps
All Events,
Events Above Threshold
3 dB to 10 dB in
1 dB steps
1.4000 to 1.6000
-100 dB to -40 dB
Factory Default
IntelliTrace
Fiber Scan dependent
Fiber Scan dependent
Fiber Scan dependent
SM: 0.05 dB
MM: 0.05 dB
–40.0 dB
Events Above Threshold
5 dB
1.4680: 1310 SM
1.4685: 1550 SM
1.4690: 1625 SM
1.4776: 850 MM
1.4719: 1300 MM
-80.3 dB: 1310 SM
-82.3 dB: 1550 SM
-82.8 dB: 1625 SM
-62.3 dB: 850 MM
-69.7 dB: 1300 MM
Setups
1–11
