Keyboard Definitions
The functions of the TFS3031's front-panel controls can be
duplicated using an optional keyboard connected to the keyboard
connector (on upgraded instruments and instruments with serial
numbers B030000 and above).
The instrument accepts text entry from the keyboard whevever a
character-selection box is on the display (i.e., when entering fiber
notes, a file name, or event notes). Table 5–15 lists the keyboard's
text-entry functions.
Table 5–15: Text-Entry Functions
Key
Backspace
Delete
Del (keypad)
Home
End
Page Down
Esc
Return
TFS3031 TekRanger/TekRanger 2 User Manual
Delete the character to the left of the cursor
Delete the character that the cursor is on
Move the cursor to the beginning of the text being
edited
Move cursor to the end of the text being edited
Delete all characters from the cursor to the end of the
text being edited
Move the cursor to the left and right
Undo
Done
Function
5–17
