Testing A Fiber
A symbol located under the distance scale indicates a
user-placed event. (There are no user-placed events in
Figure 2–2).
See page 2–23 for information about adding user-placed
events.
Information boxes at top and bottom screen display
measurement data for events marked by cursors A and B.
The boxes at top screen and the Event display at bottom
screen can be turned on and off in the Format Setup
menu.
Distance measurements from the front panel to the
locations of cursors A and B are displayed at the top of
each cursor.
The softkey accesses the setup menus.
See page 1–9 for information about instrument setups.
The softkey accesses menus for storing,
loading, copying, and deleting test files in internal
memory and floppy disk; printing files on an external
printer; and copying files to a personal computer.
See pages 2–29, 2–43, and 2–49 for information about
storing, loading, copying, deleting, and printing test
files.
The softkey allows adding user-placed
events to the waveform, and accesses the
softkey for adding notes to events.
See page 2–23 for information about adding user-placed
events.
See page 2–26 for information about adding notes to
events.
The softkey toggles between the waveform
and event table screens.
The softkey activates waveform
zooming for optimum viewing and precise cursor
TFS3031 TekRanger/TekRanger 2 User Manual
2–9
