Using the SELECT Button and Arrow Keys

Waveform options are Cursor, Zoom, and Trace. The only event table
option is Table.
After selecting an option, push the arrow keys to execute the various
functions.
Cursor
Zoom
Trace
Figure 2–6:
SELECT Button Options
Cursor. The Cursor option moves the active cursor along the
waveform. When Cursor is selected:
The
The
The
The
event.
TFS3031 TekRanger/TekRanger 2 User Manual
button options are displayed in lower right screen.
Move Left
Move Right
Next Event
Prev Event
SELECT
Options
(Waveform)
Button Options
arrow key scrolls the active cursor left.
arrow key scrolls the active cursor right.
arrow key jumps the active cursor right to the next event.
arrow key jumps the active cursor left to the previous
Testing A Fiber
Table
Shift Left
Shift Right
Prev Event
Next Event
SELECT
Options
(Event Table)
