Step 4. Power on the TFS3031. If necessary, complete a new test.
Step 5. Push the
Step 6. Push the
Step 7. Push the
Step 8. The first four fiber notes for the current file are displayed on
Step 9. Configure the TFS3031 for the printer in use.
TFS3031 TekRanger/TekRanger 2 User Manual
source of the file to be printed, then use the arrow keys to
select the file for printing.
To print a newly completed test that is not in memory,
select the Current Acquisition file at the top of the screen.
the Print screen.
If the current acquisition is selected, you can enter and edit
fiber notes for the current acquisition before printing, by
pressing the
instructions on adding and editing fiber notes.
If a file on floppy disk or in internal memory is selected, the
softkey is replaced by the
Press the
the selected file.
Push the
select and change these setups:
Printer
Select type of printer being used. Seiko DPU411 is the
default.
Print Content
When printing the Current Acquisition (current test), the
Print Content setup determines printer output.
When printing a single file from storage, what gets
printed depends on the Print Content setup, and file
softkey.
button to select the Print option.
softkey to select the memory
softkey. Refer to page 2–33 for
softkey to display all fiber notes for
softkey. Use the arrow keys to
Printing Files
softkey.
2–47
