Setups

Instrument setups establish the operating parameters of the TFS3031.
Always check and verify setups before testing a fiber. Incorrect
setups can result in inaccurate test results.

The Setup Menus

To access the setup menus, push the
The setup menus are:
Test Setup. Configures the TFS3031 to the specifications of the
fiber under test.
Format Setup. Selects the type and amount of test data to be
displayed on the screen.
System Setup. Sets the internal time and date clocks, and
backlight time-out. Adjusts display contrast. Selects instrument
language. Establishes power-on default setups.
I/O–Doc Setup. Establishes external port, printer, and file setups.
Defines your company name that will be displayed on the
power-on screen and printouts.
Setup menu selections are displayed in the bottom right corner of the
screen (see Figure 1–2 on page 1–10).
Select each setup menu by pushing the
change individual setups by pushing the arrow keys. Setups are in
effect when they are highlighted on the screen.
To exit setups and resume testing, push the
push the
TFS3031 TekRanger/TekRanger 2 User Manual
softkey first then the
softkey.
button. Access and
button. Or
button.
1–9
