Setups
Distance Tolerance
Distance tolerance is the repeatability of the distance measurement at
each event.
In the event table display, Distance Tolerance specifies the position
of the Distance Tolerance data column relative to the other columns
in the table, or turns the Distance Tolerance column off.
Selections are columns 1 through 10; Off. Factory default is off.
Distance Delta (Between Events)
Distance delta is the distance between an event and the preceding
event.
In the event table display, Distance Delta specifies the position of the
Distance Delta data column relative to the other columns in the table,
or turns the Distance Delta column off. The data is for events marked
by cursor A and cursor B.
Selections are columns 1 through 10; Off. Factory default is
column 7.
