Table 5–4: RS232 Serial Port
DB9 Configuration as DTE
Flow Control
Baud Rate
Serial Cable Information
You must use a serial cable to connect the TFS3031 to a personal
computer. Use either the Tektronix cable listed as an optional
accessory (see Table 5–10 on page 5–11), or build your own serial
cable based upon the pinout table on page 5–6. The TFS3031 serial
port matches a PC/AT DB9 exactly.
A serial cable can also be used with the TFS3031-compatible
printers. However we recommend using parallel cables for printers
whenever possible.
From TFS3031
(Male DB9)
1 DCD (Input)
2 RD (Input)
3 TD (Output)
4 DTR (Output)
5 GND
6 DSR (Input)
7 RTS (Output)
8 CTS (Input)
9 RI (Input)
TFS3031 TekRanger/TekRanger 2 User Manual
Requirement
Serial Cable Build Procedure
To Seiko
(Female DB25)
2 RD (Input)
7 GND
5 BUSY (Output)
Specification
EIA–RS232C IBM AT male
None, RTS/CTS, XON/XOFF,
DTR
1200, 2400, 4800, 9600, 19200,
38400 bps
To Epson
(Female DB25)
3 RD (Input)
7 GND
20 DTR (Output)
Specifications
