7.1.1 General Device and Diagnosis Information

Homepage
To display the ILX69-PBM homepage, click FUNCTIONS > Homepage.
Parameter
Module Name
Ethernet Address (MAC) The MAC Address (=MAC-ID) is the unique (physical) Ethernet
IP Address
Product Revision
Firmware Version Date
Serial Number
ProSoft Technology, Inc.
Description
Name of the device as character string defined by the
manufacturer
address of the device fixed by the manufacturer
IP address of the ILX69-PBM that can be set via the ProSoft fdt
Configuration Manager.
The IP address must be unique. The IP address 0.0.0.0
indicates that no IP address has been configured yet.
Revision of the ILX69-PBM firmware
Time stamp of the firmware
Serial number of the ILX69-PBM
Diagnostics and Troubleshooting
User Manual
Range of
Value/Value
ILX69-PBM
Assigned MAC
Address
Valid IP address
V1.0.0.0 to VX.X.x.x
Year-Month-Day
0 to 65535
