DPV1 Alarm Response
This message is used to send a DPV1 Alarm Response to a slave device. The message
acknowledges the alarm when the appropriate indication appears in the DPV1 Alarm
indication area. The information mapped to this area must be used in the DPV1 Alarm
Response message in order to process the alarm properly. The mapping of this
information is as follows.
ILX69PBM.CONTROL.DPV1.Alarm.Request.
Parameter
Status
Command
SlaveAddress
AlarmType
SlotNumber
Specifier
Function
Reserved
ILX69PBM.CONTROL.DPV1.Alarm.Response.
Parameter
Status
Command
SlaveAddress
AlarmType
SlotNumber
Specifier
Function
ErrorDecode
ErrorCode1
ErrorCode2
ProSoft Technology, Inc.
Data Type Value
DINT 0x0000
DINT 0x221C
SINT 0 to 125
SINT 0 to 255
SINT 0 to 255
SINT 0 to 255
SINT 0
SINT -
Data Type Value
...
DINT
DINT 0x221D
SINT 0 to 125
SINT 0 to 255
SINT 0 to 255
SINT 0 to 255
SINT 0
SINT 0 to 255
SINT 0 to 255
SINT 0 to 255
Description
ILX69-PBM Status
Command code
Slave address causing the alarm
Type of alarm
Slot number of slave causing the alarm
Alarm specifier
Reserved, set to 0
N/A
Description
ILX69-PBM Status. 0 = OK
Command code
Slave address causing the alarm
Type of alarm
Slot number of slave causing the alarm
Alarm specifier
Reserved, set to 0
A value of 128 indicates a DPV1 error
DPV1 Error code 1
DPV1 Error code 2
