ProSoft Technology ILX69-PBM User Manual page 80

Communication
User Manual
Name
Reserved
SlaveDeactivated
Reserved0...6
ExtendedDiagnostic
Overflow
MasterAddress
IdentNumber
Set Slave Control
This request makes it possible to send commands to one or several slaves. This request
makes it possible to do Sync and Freeze functions. The MSG instruction Request /
Confirmation format is as follows.
ILX69PBM.CONTROL.SlaveControl.SetSlaveControl.
Parameter
Initiate
Address
MSGStatus
SlaveCommand
MSGStatus - Message Status
Parameter
Done
Error
DoneCount
ErrorCount
SlaveCommand - Slave Command
Parameter
ClearData
UnFreeze
Freeze
nSync
Sync
GroupSelect
Page 80 of 113
Data Type Description
BOOL Reserved
BOOL Slave not active
BOOL Reserved
BOOL Slave has a large amount of diagnostics data and cannot send
it all
SINT Corresponding master address
INT PROFIBUS Identification number
Data Type Value
BOOL 0x0000
SINT 0 to 125
- -
- -
Data Type Description
BOOL Message Status is available
BOOL Last message was transmitted with an error
DINT OK response count
DINT Error message count
Data Type Description
BOOL Clears output data
BOOL Unfreezes input data
BOOL Freezes input data
BOOL Neutralizes the sync or unsync command
BOOL Freezes output data until the sync command is neutralized
SINT[8] Group Select, see below.
ILX69-PBM ♦ CompactLogix™ or MicroLogix™ Platform
PROFIBUS Master Communication Module
Description
Triggers the Get Slave Diagnostic command
Slave address
Message Status, see below
Slave Command, see below
ProSoft Technology, Inc.
