ILX69-PBM ♦ CompactLogix™ or MicroLogix™ Platform
PROFIBUS Master Communication Module
Adding a Slave to the Project
1
In the ProSoft fdt Configuration Manager project screen, locate the slave in the slave
catalog.
2
Drag and drop the slave onto the magenta PROFIBUS network line.
ProSoft Technology, Inc.
Configuration and Start-Up
User Manual
Page 39 of 113
