Station Status_3
Slave device status information (continued)
Bit Member
Offset Name
0 to 6 Reserved0..6
7 ExtDiagOverflow
DPV1 Alarm Indication
Bytes 80 to 87 contain the DPV1 Alarm Indication registers. These registers provide
incoming alarm indication data required to respond to a DPV1 alarm that originates from
a slave.
Byte Member
Offset Name
80 Alarm_Status
81 AlarmCnt
82 Rem_Add
83 Slot_Number
84 Seq_Nr
85 Alarm_Type
86 Alarm_Spec
87 Reserved
Alarm_Status
Bit Member
Offset Name
0 AlarmInd
1 Reserved
2 Reserved
3 Reserved
4 Reserved
5 Reserved
6 Reserved
7 AlarmOverrun
ProSoft Technology, Inc.
Data Description
Type
BOOL Reserved, set to 0
BOOL Slave has a large amount of diagnostics data and
cannot send it all at once
Data Description
Type
SINT Status of Alarm Pending, see table below
SINT Alarm Counter
SINT Address of slave with Alarm (0 to 126)
SINT Slot Number (0 to 254)
SINT Sequence Number (0 to 31)
SINT Alarm Type (1 to 6, 32 to 126)
SINT Alarm Specification (0 to 7)
SINT Reserved, set to 0
Data Description
Type
BOOL Alarm Indication
BOOL Reserved, set to 0
BOOL Reserved, set to 0
BOOL Reserved, set to 0
BOOL Reserved, set to 0
BOOL Reserved, set to 0
BOOL Reserved, set to 0
BOOL Alarm Overrun
