Technical Data - Profibus - ProSoft Technology ILX69-PBM User Manual

ILX69-PBM ♦ CompactLogix™ or MicroLogix™ Platform
PROFIBUS Master Communication Module
Environmental Specifications
Environmental
Specifications Type
Emission
Immunity
Climate Test
Mechanical Test
8.2

Technical Data - PROFIBUS

Parameter
Maximum number of supported DPV0/DPV1 slaves
Maximum number of total cyclic input data
Maximum number of total cyclic output data
Maximum number of cyclic input data
Maximum number of cyclic output data
Configuration data maximum
Parameterization data per slave
Acyclic communication DPV1
Maximum number of acyclic read/write
Redundancy function
Baud rate
Data transport layer
Limitations
Reference to firmware/stack version
ProSoft Technology, Inc.
Measurements
Radiated Emission E-Field
Conducted Emission
Immunity to Electrostatic
Discharge (ESD)
Immunity to Burst
Immunity to Surge
Immunity to Radiated
Electromagnetic Field
Immunity to Conducted RF
Dry Heat Withstand
Cold Withstand
Dry Heat Immunity
Cold Immunity
Vibration Sinusoidal
Shock Test
Value
DIN EN 61131-2; CISPR 16, EN 55011
DIN EN 61131-2; CISPR16, EN55011
DIN EN 61131-2; IEC 61000-4-2
DIN EN 61131-2; IEC 61000-4-4
DIN EN 61131-2; IEC 61000-4-5
DIN EN 61131-2; IEC 61000-4-3
DIN EN 61131-2; IEC 61000-4-6
DIN EN 61131-2; Clause 6.2, DIN EN 60068; -2-2 Bb
DIN EN 61131-2; Clause 6.2, DIN EN 60068; -2-1 Ab
DIN EN 61131-2; Cl. 12.1.5 / 11.6, DIN EN 60068; -2-2 Bd
DIN EN 61131-2; Cl. 12.1.5 / 11.6, DIN EN 60068; -2-1 Ad
DIN EN 61131-2; Clause 6.3.1, DIN EN 60068; –2-6 Fc
DIN EN 61131-2; Clause 6.3.2, DIN EN 60068; –2-27 Ea
Description
125 slaves
5712 bytes (Status information is separately managed)
5760 bytes
244 bytes per slave
244 bytes per slave
244 bytes per slave
7 bytes/slave standard parameters
237 bytes/slave application specific parameters
Class 1 Read/Write
DPV1 Class 1 Alarm
DPV1 Class 2 Initiate/Read/Write/Data transport/Abort
240 bytes per slave
Supported (Requires host application program support)
9.6 kBaud, 19.2 kBaud, 45.45 kBaud, 93.75 kBaud,
187.5 kBaud, 500 kBaud 1.5 MBaud, 3 MBaud, 6 MBaud,
12 Mbaud. Auto-detection mode is not supported.
PROFIBUS FDL
DPV2 isochronous mode and slave-to-slave communication
are not supported.
The redundancy function is not supported.
V2.6.x.x
Technical Data
User Manual
Page 107 of 113
