ILX69-PBM ♦ CompactLogix™ or MicroLogix™ Platform
PROFIBUS Master Communication Module
Parameter
Configuration State
Status
Uptime
Network State
Network State
Device State
Communicating
Running
Ready
Error
Configuration State
Bus ON
Config Lock
ProSoft Technology, Inc.
Description
Shows whether the ILX69-PBM is configured or not.
Counts up the time from the last Reset/Power On.
Current status of the ILX69-PBM
Operate: Shows whether the ILX69-PBM is in OPERATION
state, e.g. in data exchange in cyclic communication. In a cyclic
data exchange, the input data or the output data of the ILX69-
PBM are transmitted to the slave.
Idle: Shows whether the ILX69-PBM is in IDLE state.
Stop: Shows whether the ILX69-PBM is in STOP state, e.g. no
cyclic data exchange is performed. The ILX69-PBM was
stopped by the CompactLogix program or it changed to the
STOP state because of a bus error.
Offline: Shows whether the ILX69-PBM is not in OPERATION
state, e.g. no cyclic communication is performed. The ILX69-
PBM is in OFFLINE state as long as it does not have a valid
configuration.
Shows whether the PROFIBUS DP master executes the
network communication.
Yes: In COMMUNICATION state. The ILX69-PBM exchanges
input/output data with at least one slave.
No: Not in COMMUNICATION state. The ILX69-PBM does not
exchange input/output data with slaves.
Shows whether the ILX69-PBM has been configured correctly.
Yes: Configuration OK
No: Configuration not OK
Shows whether the ILX69-PBM has been started correctly. The
ILX69-PBM waits for a configuration.
Yes: Device is ready
No: Device is not ready
Shows whether the ILX69-PBM has detected an error.
Yes: Error has been detected
No: No error has been detected
Shows whether the bus communication was started or stopped
by the CompactLogix program.
Yes: Bus communications have started
No: Bus communications have not started
Configuration locked shows whether the ILX69-PBM
configuration is locked, i.e. the configuration is protected against
changes.
Yes: Configuration is locked
Diagnostics and Troubleshooting
User Manual
Range of
Value/Value
Configured,
Not configured
Days, hours, minute,
seconds
Operate, Idle, Stop,
Offline
Yes, No
Yes, No
Yes, No
Yes, No
Yes, No
Yes, No
Page 91 of 113
