Communication
User Manual
DPV1 Read and Write
Code
0 = CON_OK
2 = CON_RR
3 = CON_RS
9 = CON_NR
17 = CON_NA
18 = CON_DS
25 = CON_NP
54 = CON_AD
81 hex = REJ_SE
82 hex =
REJ_ABORT
83 hex = REJ_PS
84 hex = REJ_LE
85 hex = REJ_IV
9a hex = REJ_COM
Page 86 of 113
Significance Error source Help
Service was executed N/A
without an error
Resource unavailable Slave
Requested function of Slave
master is not
activated within the
slave
No answer-data, Slave
although the slave
must respond with
data
No response of the Slave
station
Master not in the Network in
logical token ring general
No plausible reaction Slave
of remote partner
Negative response Slave
received, access
denied
Device is about to Host,
stop the DPV1 configuration
communication or the
DPV1 is not in OPEN
state
Device has stopped Slave
the DPV1
communication
automatically
A previous service is Host
still in process
The length indicator Host
msg.data_cnt
exceeds maximum
configured size
Wrong parameter in Host
request
Unknown msg.b Host
command
ILX69-PBM ♦ CompactLogix™ or MicroLogix™ Platform
PROFIBUS Master Communication Module
N/A
Slave has no buffer space left for the
requested service
Slave is not activated in its DPV1 support
Slave has not sent any data back
Check network wiring, check bus
address of slave or baud rate support
Check ILX69-PBM address or highest-
station-address of other masters.
Examine bus wiring to bus short circuits
Slave does not conform to DPV1 norm
Access denied to requested data. Check
ErrorCode1 and ErrorCode2 in response
message for further error information
DPV1 communications must be
configured to be activated by the device
A previously addressed slave has
responded with non-conform parameters
Wait for the outstanding answer first.
Parallel services are not allowed.
Reduce length of message or enlarge
maximum buffer size in ProSoft fdt
Configuration Manager or in slave data
set
Check msg.function or msg.device_adr
parameter of requested message
Correct the requested msg.b parameter
of message
