ILX69-PBM ♦ CompactLogix™ or MicroLogix™ Platform
PROFIBUS Master Communication Module
8

Technical Data

8.1

Technical Data - ILX69-PBM

Note: All technical data can be altered without notice.
ILX69-PBM
General
Communication
Controller
Integrated Memory
Host Interface
PROFIBUS
Communication
PROFIBUS Interface
Ethernet Interface
(Diagnostics Interface)
ProSoft Technology, Inc.
Parameter
Description
Function
Type
RAM
FLASH
Memory card
SD Card Connector
1769 Backplane
Supported communication
protocol
Transmission rate
Interface Type
Galvanic Isolation
Isolation Voltage
Connector
Transmission rate
Interface Type
Galvanic Isolation
Isolation Voltage
Half duplex/Full duplex
Auto-Negotiation
Value
PROFIBUS DP master module
PROFIBUS DP master slot extension module for Rockwell
CompactLogix™ 1769 system which allows the PLC to
control data exchange on a PROFIBUS network.
netX 100 processor
8 MB SDRAM
16 MB serial Flash EPROM
SD and SDHC card. Both types are supported if the card
features a SPI interface. The FAT12/16/32 formats are
supported. The exFAT format is not supported.
Capacity: Max. 4 GByte
Refer to section Removable Memory Card (page 20)
e.g. FPS009-2405-0 push/push
Rockwell backplane interface: Rockwell Mercury chip for
1769 backplane
PROFIBUS DP master
9.6 kBit/s, 19.2 kBit/s, 31.25 kBit/s, 45.45 kBit/s,
93.75 kBit/s, 187.5 kBit/s, 500 kBit/s, 1.5 MBit/s,
3 MBit/s, 6 MBit/s, 12 MBit/s
RS-485, according EN 50170, refer to section PROFIBUS
Interface (page 17)
Isolated
500 VDC (from backplane)
D-Sub female Connector, 9 pin
100 MBit/s, 10 MBit/s (depending on loaded firmware)
100 BASE-TX, 10 BASE-T
Isolated
500 VDC (from backplane)
Supported (at 100 MBit/s)
Supported
Technical Data
User Manual
Page 105 of 113
