8. Connect the other end of the red and black cables to the DUT. The positive
9. Power on the instrument and turn on the Sense function of the instrument.

2.6 Remote Interface Connection

This series power supply comes standard with four communication interfaces:
USB, LAN and CAN, and supports two optional communication interfaces:
GPIB, RS-232. You can choose one of them to communicate with your
computer.

2.6.1 USB Interface

The USB interface is located on the rear panel of the instrument. You can con-
nect the instrument to the computer via a cable with a USB interface on both
ends (USB A-type connector on one end and USB B-type connector on the
other).
The user needs to select the USB interface type in the System menu before us-
ing the USB interface. The following types are optional.
•
•
The operation steps to change the USB interface type in System Menu are as
follows.
and negative poles must be properly connected and fastened when wiring.
For details, see 5.7 Sense Function
Never touch cables or connections immediately after turning off
the instrument at the end of the test. Lethal voltages may remain
at the output terminals after turn-off. Verify that there is no dan-
gerous voltage on the output or sense terminals before touching
them.
When you use the remote interface to send SCPI instructions, if you use the
programming commands that involve modifying the instrument settings, such
as modifying the output voltage value, after completing the communication
connection between the instrument and the host computer, and after the
communication settings are completed, you must execute the SYST:REM
command firstly.
TMC: USB_TMC interface;
VCP: Virtual serial port. For Win7 system, you can download IT6000 VCP
driver from ITECH official website or contact technical support engineer; for
Win10 system, you do not need to install VCP driver.
Copyright © Itech Electronic Co., Ltd.
Inspection and Installation
(Sense).
