Edit Static PV Curve
You can edit the static PV curve and save it inside the instrument (up to 100
curve records can be saved), or you can customize the editing of the PV curve
(up to 1 can be saved).
•
Table Indicates a user-defined 4096-point I-V data table. This
menu item is reserved and can only be used in PV SAS
software sold separately. This function cannot be used in
the VFD screen.
Filter Filter the input voltage of the instrument to reduce
interference.
Low
Mid
Fast
Curve
The steps to edit a static curve locally on the instrument are as follows:
1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to
enter the function menu.
2. Use knob or Up/Down key to select 4. SAS: Off and press [Enter].
3. Press the Left/Right key to select Static and press [Enter].
4. Press the Left/Right key to select Curve and press [Enter].
5. Press the Left/Right key to select Edit and press [Enter].
6. Set the Pmp, Vmp and Formula in turns, and press [Enter].
7. Set the saved file name and press [Enter].
– Also you can set the filter speed in SAS→Filter according to the ac-
tual test needs.
Copyright © Itech Electronic Co., Ltd.
Voc Set the open-circuit voltage value.
Imp Set the maximum power current value.
Vmp Set the maximum power voltage value.
Isc Set the short-circuit current value.
The filtering speed is low speed.
The filtering speed is medium speed.
The filtering speed is high speed.
Power Supply Function
