4. After the parameter settings are complete, press [Enter].
Set the Parallel Mode
•
•
•
•
For 3U models, up to 16 units of the same model can be connected in parallel.
Taking three 3U single instruments (with operation panel) as an example, the
steps for parallel operation are as follows.
1. Ensure that the power switches of the three units and the main switch of the
2. Refer
Before connecting the system bus, you must ensure that each in-
strument is in single mode (Single).
Fiber optic cables cannot be flexed or folded. When the cable is too
long and needs to be arranged, gently wrap the cable in a circle and
gently tie it.
Before connecting the cables, ensure that the instrument power
switch is off and the main switch of the AC power input (distribu-
tion box) is off.
Before connecting 3 single instruments to the AC distribution box,
ensure that the distribution box capacity is sufficient. Refer to the
corresponding specifications for the AC input parameters of a sin-
gle instrument.
For a parallel connection between a master unit (with operation panel) and N
slave units (without operation panel), refer to the IT6000 Parallel Assembly
Instruction or the IT6000 Cabinet Assembly Instruction.
AC power distribution box are off.
Figure 5–1 Wiring connection diagram
Copyright © Itech Electronic Co., Ltd.
Basic Operation
to connect three units.
