4.6.3.6 LV124
The built-in curves LV124 can meet general requirements, test conditions and
tests of electrical and electronic components in motor vehicles up to 3.5 t. Re-
lated parameters are as below:
LV124 LV124 waveform protocol
E-02 Transient overvoltage test waveform
E-04 Jump start test waveform
E-05 Load dump test waveform
E-07 Slow decrease and increase of the supply
voltage test waveform
Ubmax
Ubmin
Ubmin
Holding
Time
E-08 Slow decrease, quick increase of the sup-
ply voltage test waveform
Ubmax
Ubmin
Ubmin
Holding
Time
E-09 Reset behavior test waveform
Ubmin
E-11 Start pulses
Cold-Start
Warm-Start
E-12 Voltage curve with intelligent generator
control
Copyright © Itech Electronic Co., Ltd.
Power Supply Function
Start voltage
Holding voltage
Voltage holding time at
Ubmin
Start voltage
Holding voltage
Voltage holding time at
Ubmin
Holding voltage
Cold start
Normal Standard experi-
mental pulse
Severe Enhanced experi-
mental pulse
Warm start
