IT-E32410-OO
IT-E32420-OO
IT-E33620-OO
For maximum current of AWG copper wire, refer to table below.
AWG
The
Maxi-
mum
Current
Value (A)
•
•
A.2 Troubleshooting
The fault information of this series of instruments is described below.
Model Specifica-
tion
240A
240A
360A
8 10
60 40
AWG (American Wire Gage), it means X wire (marked on the wire). The table
above lists current capacity of single wire at working temperature of 30°C. For
reference only.
Along with temperature, you must also consider voltage drop when selecting
wire sizes.
Although the instrument will compensate for the voltage in the wires, it is recom-
mended to minimize the voltage drop as much as possible to prevent excessive
power consumption from the instrument and poor dynamic response to load
changes. Larger diameter wire sizes will help minimize wire voltage drops. Twist-
ing or bundling wires will help reduce transient voltage drops.
Copyright © Itech Electronic Co., Ltd.
Length
A pair of red and black test ca-
1m bles with round terminals at both
ends
A pair of red and black test ca-
2m bles with round terminals at both
ends
A pair of red and black test ca-
2m bles with round terminals at both
ends
12 14 16 18
30 20 13 10
Appendix
Description
20 22 24 26
7 5 3.5 2.5
28
1.7
