Edit Edit a user-defined waveform.
unlimit-
ed
upper-
limited
lower-
limited
highly-
limited
start
voltage
Copyright © Itech Electronic Co., Ltd.
Power Supply Function
Range of unlimited operating capabil-
ity, with the following settings:
•
V1: Voltage in interval 1
•
V2: Voltage in interval 2
•
V3: Voltage in interval 3
•
V4: Voltage in interval 4
Range of upper limited operating ca-
pability, with the following settings:
•
V1: Voltage in interval 1
•
V2: Voltage in interval 2
•
V3: Voltage in interval 3
•
V4: Voltage in interval 4
•
V5: Voltage in interval 5
•
V6: Voltage in interval 6
Range of lower limited operating ca-
pability, with the following settings:
•
V1: Voltage in interval 1
•
V2: Voltage in interval 2
•
V3: Voltage in interval 3
•
V4: Voltage in interval 4
•
V5: Voltage in interval 5
•
V6: Voltage in interval 6
Range of highly limited operating ca-
pability, with the following settings:
•
V1: Voltage in interval 1
•
V2: Voltage in interval 2
•
V3: Voltage in interval 3
•
V4: Voltage in interval 4
•
V5: Voltage in interval 5
Set the initial output voltage of the in-
strument before the LV123 regulation
waveform test. At the same time, this
value is also the end voltage after the
