SBC84831 All-In-One Capa Board User's Manual
1.1

Specifications

CPU
®
Intel Atom
System Chipset
®
Intel 945GSE & ICH7M
Front-Side Bus
533 MHz
BIOS
American Megatrends Inc. BIOS.
8Mbit SPI Flash, DMI, Plug and Play
"Load Optimized Default" to backup customized Setting in
the BIOS flash chip to prevent from CMOS battery fail
System Memory
One 200-pin unbuffered DDR2 SO-DIMM sockets
Maximum to 1GB DDR2 400/533 MHz memory
Onboard Multi I/O
Controller: Winbond W83627UHG
Serial Ports: Six ports for RS-232
Two SATA-150 connectors
™
CompactFlash
One CompactFlash™ Type II Socket
USB Interface
Four USB ports with fuse protection and complies with USB
Spec. Rev. 2.0
Display
CRT connector
One 40-pin connector for 24-bit dual channel LVDS via
Chrontel CH7308B from SDVO as EFP port and one 7-pin
inverter connector(Optional)
2
TM
processor N270
Socket
Introduction
