SBC84831 All-In-One Capa Board User's Manual
2.3.10 COM1 Mode Selection Jumper (JP10)
The jumper selects the COM1 ports' DCD and RI mode.
Description
COM1
16
Function
Jumper Setting
Pin 1=5V
Pin 1=DCD
(Default)
Pin 9=12V
Pin 9=RI
(Default)
