SBC81700 VIA V4 SBC User's Manual
1.1

Specifications

CPU
VIA V4 C7/Eden processors
System Chipset
VIA CN700 + VT8237R-Plus
Front-Side Bus
Differential Host Clock of 400 MHz
BIOS
Phoenix-Award PnP Flash BIOS
System Memory
Two 240-pin DDR2 DIMM sockets
Maximum up to 2GB DDR2 memory
L2 Cache
Integrated in CPU
Onboard Multi-I/O
Parallel Port -- 26-pin 2.54 pitch box-header with
SPP/EPP/ECP supported
Serial Port
10-pin 2.54 pitch box-header for RS-232
10-pin 2.54 pitch box-header for RS-232/422/485
with jumper selectable, RS-485 with auto-flow control
Floppy controller –34-pin 2.54 pitch box-header to support
two drives (1.44MB for each)
USB Interface
Six USB ports compliant with USB Spec. Rev. 2.0
VGA Controller
Chipset
Optimized Unified Memory Architecture (UMA)
Supports 16 / 32 / 64 MB Frame Buffers size
Graphics engine clocks up to 200 MHz decoupled
2
Introduction
