SBC84831 All-In-One Capa Board User's Manual

2.4.4 LVDS Flat Panel Connector (CN3)

The board has a 40-pin connector CN3 for LVDS Interface LCD. It is
strongly recommended to use the matching GLA1001WV-S-2x20P 40-
pin connector for LVDS on the board.
Pin Signal
1 VCCM
3 VCCM
5 VCCM
7 N.C.
9 GND
Channel B D3- (24-Bit
11
support)
Channel B D3+ (24-Bit
13
support)
15 GND
17 Channel B CLK-
19 Channel B CLK+
21 GND
23 Channel A D0-
25 Channel A D0+
27 GND
29 Channel A D1-
31 Channel A D1+
33 GND
35 Channel A D2-
37 Channel A D2+
39 GND
20
Pin Signal
2 VCCM
4 VCCM
6 VCCM
8 N.C.
10 GND
12 Channel B D0-
14 Channel B D0+
16 GND
18 Channel B D1-
20 Channel B D1+
22 GND
24 Channel B D2-
26 Channel B D2+
28 GND
Channel A D3- (24-Bit
30
support)
Channel A D3+ (24-Bit
32
support)
34 GND
36 Channel A CLK-
38 Channel A CLK+
40 GND
Jumpers and Connectors
