Watchdog Timer Setting
After the system stops working for a while, it can be auto-reset by the
Watchdog Timer. The integrated Watchdog Timer can be set up in the
system reset mode by program.
Using the Watchdog Function
Start
↓
Un-Lock WDT:
↓
Select Logic device:
↓
Activate WDT:
↓
Set Second or Minute :
↓
Set base timer :
↓
; IF to disable WDT:
Watchdog Timer
SBC84831 All-In-One Capa Board User's Manual
WATCHDOG TIMER
O 2E 87 ; Un-lock super I/O
O 2E 87 ; Un-lock super I/O
O 2E 07
O 2F 08
O 2E 30
O 2F 01
O 2E F5
O 2F N N=00 or 08
O 2E F6
O 2F M=00,01,02,...FF(Hex) ,Value=0 to 255
O 2E 30
O 2F 00 ; Can be disable at any time
