SBC81205 Core™ 2 Quad SBC User's Manual
1.1

Specifications

®
CPU: Intel Core
processors
System Chipset: Intel
CPU Socket: LGA775
Front-Side Bus: 800/1066/1333 MHz
BIOS
Phoenix-Award PnP Flash BIOS
System Memory
Two x 240-pin DDR2 DIMM sockets
Maximum up to 4GB DDR2 memory
Support DDR-667/800 memory
L2 Cache: integrated in CPU
Onboard Multi-I/O
Parallel Port: one bi-directional with ECP/EPP/SPP support
Serial Port: one for RS-232 (COM1) and one port for
RS-232/422/485 (COM2)
Floppy controller: supports two drives (1.44MB for each)
USB Interface
Six USB ports compliant with USB Spec. Rev. 2.0
VGA Controller
Chipset Integrated VGA Controller and Supports up to
2048x1536 at 75 Hz resolution on non-interlaced CRT
monitors
Ethernet
The LAN1/LAN2: dual Realtek RTL8111B gigabit Ethernet
controller
Via PCI Express x1 bus
Wake-on-LAN support
Serial ATA
Built-in four SATA/SATA II ports onboard support the
maximum transfer rate up to 3 Gb/sec
2
TM TM
2 Quad, Core 2 Duoand Celeron
®
Q35 & ICH9/ICH9R
®
Introduction
