  • Page 1 SBC84830 Series ® ™ Intel Core Duo All-In-One ECX Board User’s Manual...
  • Page 2 AXIOMTEK does not warrant or assume any legal liability or responsibility for the accuracy, completeness or usefulness of any information in this document. AXIOMTEK does not make any commitment to update the information in this manual.
  • Page 3 Wear a wrist-grounding strap, available from most electronic component stores, when handling boards and components. Trademarks Acknowledgments AXIOMTEK is a trademark of AXIOMTEK Co., Ltd. ® Windows is a trademark of Microsoft Corporation. Phoenix & AWARD are trademarks of Phoenix Technology Ltd.

  • Page 4: Table Of Contents

    Table of Contents Chapter 1 Introduction ..............1 1.1 Specifications ................ 2 1.2 Utilities Supports..............4 Chapter 2 Jumpers and Connectors ..........5 2.1 Board Layout and Fixing Holes ..........5 2.2 Placement................7 2.3 Jumper Settings..............9 2.3.1 LVDS Voltage Selection Jumper........9 2.3.2 Compact Flash Voltage Selection Jumper.....
  • Page 5 2.4.14 SATA Connectors............20 2.4.15 USB Connector USB2 ..........20 2.4.16 USB Connector USB1 ..........20 2.4.17 CPU Fan Connector ........... 21 2.4.18 Compact Flash Connector ......... 21 Chapter 3 Hardware Description..........23 3.1 Microprocessors ..............23 3.2 BIOS .................. 23 3.3 System Memory..............

  • Page 7: Chapter 1 Introduction

    The built-in Watchdog Timer has enhanced the system reliability that achieves a unique feature to distinguish itself from other boards. Designed for the professional embedded developers, the Socket M embedded board SBC84830 Series is virtually ultimate one-step solution for embedded system applications. Introduction...

  • Page 8: Specifications

    SBC84830 Series All-In-One ECX Board User’s Manual Specifications ® CPU: Socket M (478) for Intel Core Core Solo processors ® System Chipset: Intel 945GM & ICH7M CPU Frequency: 533/667MHz FSB BIOS Phoenix-Award BIOS, Y2K compliant 4Mbit Flash, DMI, Plug and Play...
  • Page 9 SBC84830 Series All-In-One ECX Board User’s Manual Graphics ® Intel 945GM GMCH Gen 3.5 integrated graphic engine CRT interface for external display devices Maximum up to 224MB frame buffer sharing system memory Maximum display resolution: CRT: 2048 x1536 LVDS: 1600 X1200 (24-bit single/dual...

  • Page 10: Utilities Supports

    SBC84830 Series All-In-One ECX Board User’s Manual Utilities Supported Chipset Driver VGA Driver Ethernet Driver Audio Driver Introduction...

  • Page 11: Chapter 2 Jumpers And Connectors

    SBC84830 Series All-In-One ECX Board User’s Manual C h a p t e r 2 Jumpers and Connectors Board Layout and Fixing Holes Component Side Jumpers and Connectors...
  • Page 12 SBC84830 Series All-In-One ECX Board User’s Manual Solder Side Jumpers and Connectors...

  • Page 13: Placement

    SBC84830 Series All-In-One ECX Board User’s Manual Placement Component Side Jumpers and Connectors...
  • Page 14 SBC84830 Series All-In-One ECX Board User’s Manual Solder Side Jumpers and Connectors...

  • Page 15: Jumper Settings

    SBC84830 Series All-In-One ECX Board User’s Manual Jumper Settings Proper jumer settings configure the SBC84830 to meet your application purpose. We are herewith listing a summary table of all jumpers and default settings for onboard devices, respectively. Here is a list of jumper settings：...

  • Page 16: Cmos Clear Jumper

    SBC84830 Series All-In-One ECX Board User’s Manual 2.3.3 CMOS Clear Jumper: JP4 You may need to use this jumper to clear the CMOS memory if incorrect settings in the Setup Utility. Options Settings Normal Short 1-2 (default) Clear CMOS Short 2-3 2.3.4 COM1, COM2 Mode Jumpers: JP5, JP6...

  • Page 17: Connectors

    Connectors connect the CPU card with other parts of the system. Loose or improper connection might cause problems. Make sure all connectors are properly and firmly connected. Here is a summary table shows you all connectors on the SBC84830 Series. Connectors Label...

  • Page 18: Power Connector

    SBC84830 Series All-In-One ECX Board User’s Manual 2.4.1 Power Connector: CN1 Signal Signal PS_ON +12V N.C. +SB5V -12V 2.4.2 Digital I/O Port (DIO) Connector: CN3 The board is equipped a digital I/O connector CN5 that meets requirements for a system customary automation control. The digital...

  • Page 19: Lvds Flat Panel Connector

    SBC84830 Series All-In-One ECX Board User’s Manual 2.4.4 LVDS Flat Panel Connector: CN4 The LVDS interface which is with 40-pin connector supports 18/24-bit single/dual channel type of LCD. Signal Signal VCCM VCCM VCCM VCCM VCCM VCCM N.C. N.C. Channel B D3-...

  • Page 20: Audio Connector

    SBC84830 Series All-In-One ECX Board User’s Manual The 7-pin inverter connector on the SBC is with Hirose connector. The matching connector is strongly recommended to use Hirose DF13-7S-1.25C. 2.4.5 Audio Connector: CN6 The board supports audio interface.CN6 is a 10pin-header connector commonly used for the audio.

  • Page 21: Serial Port Interface Connectors

    SBC84830 Series All-In-One ECX Board User’s Manual Signal Signal Signal Green Blue AGND AGND AGND DDC DAT Horizontal Sync Vertical Sync DDC CLK CN13 2.4.9 Serial Port Interface Connectors: COM1, COM2 The board has four onboard serial ports and +5V/12V power on pins 1 and 8 or pin 9, depending on jumper selection.

  • Page 22: Flat Panel Bezel Connectors

    SBC84830 Series All-In-One ECX Board User’s Manual COM2 Description Data Carrier Detect (DCD) Data Set Ready (DSR) Receive Data (RXD) Request to Send (RTS) COM2 Transmit Data (TXD) Clear to Send (CTS) Data Terminal Ready (DTR) Ring Indicator (RI) Ground (GND) N.C.

  • Page 23: Ethernet Connector

    SBC84830 Series All-In-One ECX Board User’s Manual 2.4.11 Ethernet Connector: LAN1 The RJ-45 connector is used for Ethernet. To connect the board to 100-Base-T or 1000-Base-T hub, just plug one end of the cable into LAN1 and connect the other end (phone jack) to a 100-Base-T hub or 1000-Base-T hub.
  • Page 24 SBC84830 Series All-In-One ECX Board User’s Manual Signal Signal +12V CLK_100M_PCIE0# +12V +12V PWR_PSON# SIO1_RI +5V_SBY LPC_FRAME# LPC_AD0 LPC_DRQ1# LPC_AD1 LPC_AD2 CLK_33M_SIO2 LPC_AD3 INT_SERIRQ INT_PIRQE# +3.3V INT_PIRQG# SMB_DATA_S PCI_REQ2# SMB_CLK_S CLK_33M_PCI2 CLK_48M_SIO2 PCI_REQ1# CLK_33M_PCI1 PCI_GNT1# INT_PIRQF# PCI_AD31 PCI_GNT2# PCI_AD29 PCI_AD27...

  • Page 25: Sm Bus Connector

    SBC84830 Series All-In-One ECX Board User’s Manual Signal Signal 100 +3.3V +3.3V 104 PCI_TRDY# PCI_SERR# 106 PCI_STOP# PCI_C/BE1# 108 +3.3V PCI_AD14 110 PCI_PAR 112 PCI_AD15 PCI_AD12 114 PCI_AD13 PCI_AD10 116 PCI_AD11 118 GND PCI_AD8 120 PCI_AD9 PCI_AD7 122 PCI_C/BE0# +3.3V 124 +3.3V...

  • Page 26: Sata Connectors

    SBC84830 Series All-In-One ECX Board User’s Manual 2.4.14 SATA Connectors: SATA1/SATA2 These SATA connectors are for high-speed SATA interface ports and they can be connected to hard disk devices. Signal SATA1/SATA2 STXP STXN SRXN SRXP 2.4.15 USB Connector: USB2 The Universal Serial Bus (USB) connector on the board is for the installation of peripherals supporting the USB interface.

  • Page 27: Cpu Fan Connector

    +12V Sensor 2.4.18 Compact Flash Connector: CFS1 The SBC84830 Series is equipped with a CompactFlash disk socket on the solder side and it supports the IDE2 interface CompactFlash disk card. The socket itself is specially designed to prevent any incorrect installation of the CompactFlash disk card.
  • Page 28 SBC84830 Series All-In-One ECX Board User’s Manual CFS1: Compact Flash Socket Pin Assignment Signal Signal CD1- Data 3 Data 11 Data 4 Data 12 Data 5 Data 13 Data 6 Data 14 Data 7 Data 15 CS0# CS1# Address 10...

  • Page 29: Chapter 3 Hardware Description

    Make sure your installed microprocessor with all correct settings that prevents the CPU from damages. BIOS The SBC84830 Series uses Award Plug and Play BIOS with a single 4Mbit Flash EPROM. System Memory The SBC84830 Series industrial CPU card supports one 200-pin DDR2 DIMM sockets for a maximum memory of 2GB DDR2 SDRAMs.

  • Page 30: I/O Port Address Map

    SBC84830 Series All-In-One ECX Board User’s Manual I/O Port Address Map ® The Intel Core Duo and Core Solo processors can communicate via I/O ports. There are total 1KB port addresses available for assignment to other devices via I/O expansion cards.

  • Page 31: Interrupt Controller

    SBC84830 Series All-In-One ECX Board User’s Manual Interrupt Controller The SBC84830 Series is a 100% PC compatible control board. It consists of 16 interrupt request lines, and four out of them can be programmable. The mapping list of the 16 interrupt request lines is shown as the following table.
  • Page 32 SBC84830 Series All-In-One ECX Board User’s Manual Hardware Description...

  • Page 33: Chapter 4 Award Bios Utility

    SBC84830 Series All-In-One ECX Board User’s Manual C h a p t e r 4 Award BIOS Utility The Phoenix-Award BIOS provides users with a built-in Setup program to modify basic system configuration. All configured parameters are stored in a battery-backed-up RAM (CMOS RAM) to save the Setup information whenever the power is turned off.

  • Page 34: Control Keys

    SBC84830 Series All-In-One ECX Board User’s Manual Control Keys Move cursor to the previous item Up arrow Move cursor to the next item Down arrow Move cursor to the item on the left hand Left arrow Move to the item in the right hand...

  • Page 35: The Main Menu

    SBC84830 Series All-In-One ECX Board User’s Manual The Main Menu Once you enter the Award BIOS CMOS Setup Utility, the Main Menu appears on the screen. In the Main Menu, there are several Setup functions and a couple of Exit options for your selection. Use arrow keys to select the Setup Page you intend to configure then press <Enter>...

  • Page 36: Standard Cmos Setup Menu

    SBC84830 Series All-In-One ECX Board User’s Manual Standard CMOS Setup Menu The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp>...
  • Page 37 SBC84830 Series All-In-One ECX Board User’s Manual IDE Channel 0/1 Master/Slave These items identify the types of each IDE channel installed in the computer. There are 45 predefined types (Type 1 to Type 45) and 2 user’s definable types (Type User) for Enhanced IDE BIOS.

  • Page 38: Advanced Bios Features

    SBC84830 Series All-In-One ECX Board User’s Manual Press <Esc> to return to the Main Menu page. Advanced BIOS Features This section allows you to configure and improve your system and allows you to set up some system features according to your preference.
  • Page 39 SBC84830 Series All-In-One ECX Board User’s Manual Hard Disk Boot Priority Scroll to this item and press <Enter> to view the sub menu to decide the disk boot priority. Press <Esc> to return to the Advanced BIOS Features page. CPU L1 & L2 Cache These two options speed up memory access.
  • Page 40 SBC84830 Series All-In-One ECX Board User’s Manual First/Second/Third Boot Device These items let you select the 1 , and 3 devices that the system will search for during its boot-up sequence. The wide range of selection includes Floppy, LS120, ZIP100, HDD0~3, SCSI, and CDROM.
  • Page 41 SBC84830 Series All-In-One ECX Board User’s Manual 24 characters per second 30 characters per second -- End of Typematic Rate Table -- Typematic Delay (Msec) This option defines how many milliseconds must elapse before a held-down key begins generating repeat characters. The default value is “250”.

  • Page 42: Advanced Chipset Features

    SBC84830 Series All-In-One ECX Board User’s Manual If enabled, the EPA logo will appear during system booting up; if disable, the EPA logo will not appear. Advanced Chipset Features Since the features in this section are related to the chipset on the CPU...
  • Page 43 SBC84830 Series All-In-One ECX Board User’s Manual allowed, refresh may be incomplete and the DRAM may fail to retain data. Precharge Delay <tRAS> The precharge time is the number of cycles it takes for DRAM to accumulate its charge before refresh.

  • Page 44: Integrated Peripherals

    SBC84830 Series All-In-One ECX Board User’s Manual Integrated Peripherals This section allows you to configure your SuperIO Device, IDE Function and Onboard Device. OnChip IDE Device Scroll to this item and press <Enter> to view the sub menu OnChip IDE Device.
  • Page 45 SBC84830 Series All-In-One ECX Board User’s Manual IDE DMA transfer access Automatic data transfer between system memory and IDE device with minimum CPU intervention. This improves data throughput and frees CPU to perform other tasks. On-Chip Primary/Secondary PCI IDE The integrated peripheral controller contains an IDE interface with support for two IDE channels.
  • Page 46 SBC84830 Series All-In-One ECX Board User’s Manual request (IRQ) for the onboard parallel port. SATA Port If the “PATA IDE Mode“ is Primary, it will show ” P1, P3 is Secondary” which means SATA 2 and SATA 4 are Secondary. If the “PATA IDE Mode “ is Secondary, it will show “...
  • Page 47 SBC84830 Series All-In-One ECX Board User’s Manual Press <Esc> to return to the Integrated Peripherals page. Super IO Device Scroll to this item and press <Enter> to view the sub menu Super IO Device. Onboard Serial Port 1 / 2 Select an address and corresponding interrupt for the serial port.

  • Page 48: Power Management Setup

    SBC84830 Series All-In-One ECX Board User’s Manual Power Management Setup The Power Management Setup allows you to save energy of your system effectively. It will shut down the hard disk and turn OFF video display after a period of inactivity.
  • Page 49 SBC84830 Series All-In-One ECX Board User’s Manual Standby mode in S1 (POS) or S3 (STR) fashion through the setting of this field. Options are: [S1 (POS)] The S1 sleep mode is a low power state. In this state, no system context is lost (CPU or chipset) and hardware maintains all system contexts.
  • Page 50 SBC84830 Series All-In-One ECX Board User’s Manual Suspend Mode After a selected period of system inactivity (1 minute to 1 hour), all devices except the CPU shut off. The default value is “Disabled”. Disabled The System will never enter the SUSPEND mode.

  • Page 51: Pnp/Pci Configuration Setup

    SBC84830 Series All-In-One ECX Board User’s Manual ** Reload Global Timer Events ** Global Timer (power management) events can prevent the system from entering a power saving mode or can awaken the system from such a mode. Primary/Secondary IDE 0/1 Use this item to configure the IDE devices monitored by the system.
  • Page 52 SBC84830 Series All-In-One ECX Board User’s Manual or if installing a new add-on cause the system reconfiguration a serious conflict that the operating system can not boot. Options: Enabled, Disabled. Resources Controlled By The Award Plug and Play BIOS can automatically configure all boot and Plug and Play-compatible devices.

  • Page 53: Pc Health Status

    SBC84830 Series All-In-One ECX Board User’s Manual 4.11 PC Health Status This section supports hardware monitering that lets you monitor those parameters for critical voltages, temperatures and fan speed of the board. CPU Temperature The current system CPU temperature will be automatically detected by the system.

  • Page 54: Frequency/Voltage Control

    SBC84830 Series All-In-One ECX Board User’s Manual 4.12 Frequency/Voltage Control This section is to control the CPU frequency and Supply Voltage, DIMM OverVoltage and AGP voltage. Auto Detect PCI Clk The enabled item can automatically disable the clock source for a PCI slot without a module, to reduce EMI (ElectroMagnetic Interference).

  • Page 55: Load Optimized Defaults

    SBC84830 Series All-In-One ECX Board User’s Manual 4.13 Load Optimized Defaults This option allows you to load your system configuration with default values. These default settings are optimized to enable high performance features. To load CMOS SRAM with SETUP default values, please enter “Y”. If not, please enter “N”.

  • Page 56: Set Supervisor/User Password

    SBC84830 Series All-In-One ECX Board User’s Manual 4.14 Set Supervisor/User Password You can set a supervisor or user password, or both of them. The differences between them are: Supervisor password: You can enter and change the options on the setup menu.

  • Page 57: Save & Exit Setup

    SBC84830 Series All-In-One ECX Board User’s Manual 4.15 Save & Exit Setup This section allows you to determine whether or not to accept your modifications. Type “Y” to quit the setup utility and save all changes into the CMOS memory. Type “N” to bring you back to the Setup utility.

  • Page 58: Exit Without Saving

    SBC84830 Series All-In-One ECX Board User’s Manual 4.16 Exit Without Saving Select this option to exit the Setup utility without saving changes you have made in this session. Type “Y”, and it will quit the Setup utility without saving your modifications. Type “N” to return to the Setup utility.

  • Page 59: Appendix A Watch Dog Timer

    SBC84830 Series All-In-One ECX Board User’s Manual A p p e n d i x A Watch Dog Timer Watchdog Timer Setting The watchdog timer makes the system auto-reset while it stops working for a period. The integrated watchdog timer can be setup as system reset mode by program.
  • Page 60 SBC84830 Series All-In-One ECX Board User’s Manual Using the Watchdog Function Start ↓ Un-Lock WDT: O 2E 87 ; Un-lock super I/O O 2E 87 ; Un-lock super I/O ↓ Select Logic device: O 2E 07 O 2F 00 Set WDT Funtion:...
  • Page 61 SBC84830 Series All-In-One ECX Board User’s Manual 1sec 50sec 180sec 992sec 2sec 55sec 190sec 2012sec 3sec 60sec 200sec 3032sec 4sec 65sec 210sec 3992sec 5sec 70sec 220sec 5012sec 6sec 75sec 230sec 6032sec 7sec 80sec 240sec 6992sec 85sec 8sec 250sec 8012sec 10sec...
  • Page 62 SBC84830 Series All-In-One ECX Board User’s Manual Watch Dog Timer...

  • Page 63: Appendix B Digital I/O

    SBC84830 Series All-In-One Mini ITX Board User’s Manual A p p e n d i x B Digital I/O Using the Digital I/O Function Start ↓ Un-Lock SuperI /O: O 2E 87 ; Un-lock super I/O O 2E 87 ; Un-lock super I/O ↓...
  • Page 64 SBC84830 Series All-In-One ECX Board User’s Manual Digital I/O...
