2.3.11 COM2 Mode Selection Jumper (JP11)
The jumper selects the COM2 ports' DCD and RI mode.
Description
COM2
Jumpers and Connectors
SBC84831 All-In-One Capa Board User's Manual
Function
Jumper Setting
Pin 1=5V
Pin 1=DCD
(Default)
Pin 8=12V
Pin 8=RI
(Default)
